DuroZone RD-Series Dampers to Zone Control Panel Hookups
All other Panels: The DuroZone RD-Series dampers can be controlled by hooking 24 Common to damper terminal 1, 24vac hot to terminal 2, and then switching 24vac hot to terminal 4: Power to terminal 4 causes the damper to open: removing power causes the damper to close. For control by most thermostats, hook damper terminal 1 to 24vac common (C), damper terminal 2 to 24vac hot (R), then damper terminal 4 to thermostat Y and W (jumper W and W stat terminals together.)
EWC, Older EWC, Trol-A-Temp, and Durozone Panels with an “M2” Terminal
Honeywell, 432, 322, and Other Panels, Trol-A-Temp, TZ-3, TAZ Expander
Zone Panel
Zone Panel
DuroZone RD-Series Damper Motor
DuroZone RD-Series Damper Motor
Braeburn Panels
Ecojay Panels
Zone Panel
Zone Panel
DuroZone RD-Series Damper Motor
DuroZone RD-Series Damper Motor
Control Systems with PO, PC, C, or X Markings
Zone Panel
Special damper wiring instructions -
leave with damper until installed. These instructions replace instructions in box for system indicated.
Call RetroZone™ at (972) 633-8109 or e-mail support@retrozone.com for technical support.
©Copyright 1998 Enerzone
DuroZone RD-Series Damper Motor
